Parameter:
|
Model |
HPS376S-30A |
|
|
Output |
DC voltage |
28VDC |
|
Rated current |
30A |
|
|
Current range |
0～30A |
|
|
Rated power |
850W |
|
|
Ripple and Noise (Max) Note 2 |
150mVp-p |
|
|
Voltage adjustment range |
28VDC±0.5V |
|
|
Voltage accuracy (note 3) |
±1.0% |
|
|
Linear adjustment rate |
±0.2% |
|
|
Load regulation rate |
±0.2% |
|
|
DC output port |
2 terminal block output ports |
|
|
Start, rise, hold time |
200ms 80ms 20ms |
|
|
Input
|
Voltage range (note 1) |
220VAC±20%（110VAC/220VAC Automatic switching, automatic battery switching） |
|
Frequency Range |
50Hz±20﹪ |
|
|
Efficiency |
≥80% |
|
|
Power factor |
≥0.95 |
|
|
Inrush Current |
Slow start, maintain 4A for 10ms |
|
|
DC input voltage |
24VDC with battery charging and battery management functions |
|
|
Protect
|
Input protection |
The front panel has a (24V battery) 30A fuse, and the rear panel AC socket has a 10A fuse. |
|
Overload |
When the set current value is exceeded, overcurrent protection is activated. |
|
|
Protection mode: The voltage drops rapidly and can automatically recover after exiting the overcurrent protection. |
||
|
Overload protection |
Output current limit 33A |
|
|
Overvoltage protection |
＜32V |
|
|
Environment |
Working temperature, humidity |
-10℃～+55℃ 20～95%RH |
|
Storage temperature, humidity |
-20℃～+85℃ 10～95%RH |
|
|
Temperature Coefficient |
±0.03﹪/℃（0～50℃） |
|
|
Vibration resistant |
Carry out according to X, Y, Z axis, 10～500Hz, 2G 10 minutes/cycle, 60 minutes in total |
|
