Specification：
|
Modle No |
DC24-4810 |
DC48-1230 |
DC48-2415 |
|
|
Output |
DC Voltage |
48V |
13.8V |
24V |
|
Rated Current |
10A |
30A |
15A |
|
|
Current Range |
0-10A |
0-30A |
0-15A |
|
|
Rated Power |
480W |
414W |
360W |
|
|
Ropple & Noise Max |
100mVp-p |
100mVp-p |
100mVp-p |
|
|
Voltage Precision |
±1.0% |
±1.0% |
±1.0% |
|
|
Line Regulation |
±0.2% |
±0.2% |
±0.2% |
|
|
Load Regulation |
±0.2% |
±0.2% |
±0.2% |
|
|
Startup,Rising,Keeping Time |
200ms 80ms 20ms |
|||
|
Input |
Voltage Range |
22～27VDC |
40～60VDC |
40～60VDC |
|
Efficiency |
≥80% |
≥80% |
≥80% |
|
|
Protection |
Over Load |
When over setting current,it would start over current protection |
||
|
Protection mode:when rapid decline in voltage,and current revert under currentrange,it will resume automatically |
||||
|
Environment
|
Operation Temperature,Humidity |
10～+45℃ 20～90%RH |
||
|
Storage Temperature,Humidity |
-20～+85℃ 10～95%RH |
|||
|
Temperature Coefficient |
±0.03﹪/℃（0～50℃） |
|||
|
Vibration |
By X,Y,Z axes,10~500HZ,2G 10min/period,total 60minutes |
|||
|
Safety and Battery |
Safty Codes |
Comply with UL1012 |
||
|
Compression Strength |
I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC |
|||
|
Insulation Resistance |
I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC 70﹪RH |
|||
|
Electromagnetic Interference(EMI) |
Comply with FCC Part 15j Conduction Class B |
|||
|
Others |
MTBF |
322.4K hrs min.MIL-HDBK-217F(25℃) |
||
|
Dimension |
350＊190＊60mm(L＊W＊H) |
|||
|
Packing |
2.5Kg Pc/bo×1pc |
|||
|
Remarks |
1, DC24-4810, DC24-1230 rated input voltage is 24VDC, DC48-1230, DC48-2415 rated input voltage is 48V, measured at rated load, 25 °C ambient temperature. 2, ripple and noise measurement: use a 12’’ twisted pair, while the terminal should be connected in parallel with 0.1uF and 47Uf capacitors, measured under 20MHz bandwidth. 3, accuracy: including setting error, linear adjustment rate and load adjustment rate. |
|||
